Medium rotary screw compressors 18 – 55kW

Venti’s KME C Plus is an industrial series of belt-driven screw compressors offering low installation and management costs, with excellent performance, especially in applications requiring continuous service.

Easily manage all functions with the intuitive, user friendly controller.

With a compact footprint, easy installation, and preassembled dryers and tanks, these compressors offer space-saving benefits, eliminate the need for additional installation work, and prevent air leaks, providing significant cost savings.

Technical features

• 7.5 – 55 kW
• Belt drive
• Pack Smart VMC
• Electronic KTRONIC 10P control (KTRONIC 100P optional)
• Latest generation Star-Delta electric motor (made in Italy)
• Ultra-quiet and efficient electric fan paired with thermostatic valve for optimal performance
• Poly-V belt transmission

Industrial KME C Plus 7-55 series models

The Industrial KME C Plus 7-55 series is available in the following models:

• grounded
• grounded with dryer
• on tank
• on tank with dryer

Venti’s KLE Plus is an industrial range of direct-drive, inverter compressors offering exceptional reliability, compact design, energy efficiency, and quiet operation under all conditions.

Featuring direct transmission, advanced separation tanks, and high-efficiency motors, the KLE Plus delivers significant advantages, including:

• Simplified operation and management
• Exceptional reliability
• Energy savings
• Ultra-quiet performance
• Reduced maintenance costs

With intelligent technology, the KLE Plus minimises energy costs by adjusting the motor’s RPM, and the airend speed, to match the precise air demand of your operations, all while maintaining a consistent air pressure.

Technical features

• 15 – 55 kW
• Direct coupling
• Variable Speed Drive
• Pack Smart V90-V110-V130-V150
• K-tronic 100 touchscreen controller (optional)
• High performance electric motor: premium efficiency
• Variable speed drive motor control
• High efficiency, low-noise cooling fan
• Easy access for quick maintenance
• Oil resistant soundproof panels
• Oversized air-oil heat exchanger
• Aftercooler condense separator (37-45-55 kW)

Venti’s Heavy Industrial, two stage rotary screw compressors are available in DCT 2S and DCT 2S VSD with Variable Speed Drive.

Technical features

• 55 – 355 kW
• 2S DCT and 2S DCT VSD series offering energy efficiency and reliability for industrial use
• Venti’s two-stage screw units offer up to 15% energy savings compared to single stage screw units.
• Increased output
• Better power efficiency (kW/m3/min)
• Lower oil temperature between the first and second stages enhances the efficiency of the screw unit
• Low rotation speed allows for long bearing life.
• The use of a low-speed motor (4/6 poles in the fixed-speed version) combined with appropriately sized rotary screws (max 1500 rpm) ensures extended bearing life.
• Speed control allows for precise detection of working pressure and motor speed, ensuring the optimal flow rate based on actual air demand, which results in significant energy savings.
• User-friendly KTronic 1000 touch screen panel provides full access to all functions, parameter settings, and diagnostics, helping to boost the compressor’s efficiency. it can also connect to a local area network (LAN), enabling you to monitor and manage the compressor from a remote PC or mobile device.
• Variable Speed Drive (VSD) range is designed and sized to operate at a 100% duty cycle, even under the most demanding conditions, while maintaining energy efficiency through an inverter-controlled fan for the oil cooler.
• The compressor’s easily removable external panels allow for convenient access to components requiring routine maintenance.
• The air-oil separator cartridge can also be quickly replaced by simply rotating the tank lid, without the need for disassembly.
