Large rotary screw compressors 55 – 355kW

Nessco Pressure Systems offers rotary screw compressors from small to heavy duty capacity. Our large screw compressors range is available in sizes from 55 kW to 355 kW, including fixed speed and variable speed drive, and single and two-stage options.

Venti's range of singe stage, heavy duty industrial screw compressors are available in 75-355 kW models from Nessco Pressure Systems.

Venti’s Heavy Industrial, single stage rotary screw compressors are available in DCT (Fixed speed, single-stage rotary screw compressors with direct transmission) and DCT VSD (variable speed, single-stage rotary screw compressors with direct transmission).

Technical features

  • 75 – 315 kW
  • DCT and DCT VSD series offers energy efficiency and reliability for industrial use
  • Airend engineered for efficiency and durability – the optimised rotor profile, designed with cutting-edge fluid dynamics, minimises pressure drops within the system. This reduces energy consumption by 8%, delivering better power output.
  • Low rotation speeds extend the service life of the bearings, ensuring long-term reliability and performance.
  • The use of a low-speed motor (4/6 poles in the fixed-speed version) combined with appropriately sized rotary screws (max 1400rpm) ensures extended bearing life.
  • Speed control allows for precise detection of working pressure and motor speed, ensuring the optimal flow rate based on actual air demand, which results in significant energy savings.
  • The user-friendly KTronic 1000 touch screen panel provides full access to all functions, parameter settings, and diagnostics, helping to boost the compressor’s efficiency. It can also connect to a local area network (LAN), enabling you to monitor and manage the compressor from a remote PC or mobile device.
  • The cooling system features separate, individually managed coolers for air-to-air and air-to-oil systems, ensuring precise temperature regulation.

Venti Heavy Industrial Series Single Stage Brochure

Venti heavy duty industrial series screw compressors - single stage, supplied by Nessco Pressure Systems.

Upgrade your operations or expand your business with Venti and you’ll be investing in the latest generation of highly efficient screw compressors featuring high-quality electric motors and a design that maximises performance and durability.

Call our team on 1300 290 638 or email info@nesscopressure.com.au to find out why Venti Compressors are your ideal workshop partner.

Venti's range of two-stage, heavy duty industrial screw compressors are available in 55-315 kW models from Nessco Pressure Systems.

Venti’s Heavy Industrial, two stage rotary screw compressors are available in DCT 2S and DCT 2S VSD with Variable Speed Drive.

Technical features

  • 55 – 355 kW
  • 2S DCT and 2S DCT VSD series offering energy efficiency and reliability for industrial use
  • Venti’s two-stage screw units offer up to 15% energy savings compared to single stage screw units.
  • Increased output
  • Better power efficiency (kW/m3/min)
  • Lower oil temperature between the first and second stages enhances the efficiency of the screw unit
  • Low rotation speed allows for long bearing life.
  • The use of a low-speed motor (4/6 poles in the fixed-speed version) combined with appropriately sized rotary screws (max 1500 rpm) ensures extended bearing life.
  • Speed control allows for precise detection of working pressure and motor speed, ensuring the optimal flow rate based on actual air demand, which results in significant energy savings.
  • User-friendly KTronic 1000 touch screen panel provides full access to all functions, parameter settings, and diagnostics, helping to boost the compressor’s efficiency. it can also connect to a local area network (LAN), enabling you to monitor and manage the compressor from a remote PC or mobile device.
  • Variable Speed Drive (VSD) range is designed and sized to operate at a 100% duty cycle, even under the most demanding conditions, while maintaining energy efficiency through an inverter-controlled fan for the oil cooler.
  • The compressor’s easily removable external panels allow for convenient access to components requiring routine maintenance.
  • The air-oil separator cartridge can also be quickly replaced by simply rotating the tank lid, without the need for disassembly.

Venti-Heavy-Industrial-Series-Two-Stage-Brochure

Venti heavy duty industrial series screw compressors - two stage, supplied by Nessco Pressure Systems.

Upgrade your operations or expand your business with Venti and you’ll be investing in the latest generation of highly efficient screw compressors featuring high-quality electric motors and a design that maximises performance and durability.

Call our team on 1300 290 638 or email info@nesscopressure.com.au to find out why Venti Compressors are your ideal workshop partner.

Let our compressed air specialists help you!

With wide range of screw compressors available on the market, it can be hard to choose the one that meets your exact needs now and into the future.

By assessing your business needs and supply demand, our sales team can provide you with model suggestions that offer the best performance for your operations.

If you have any questions or would like to find out more about our range of screw compressors, get in touch with our compressed air specialists.

=
